Frequency Coverage: 50-52MHz amateur
band.
extensions and/or changes on request.
•
Power Output: 3500 W PEP or 2500 W
continuous carrier.
• Intermodulation
Distortion: Better than 35 dB below rated output.
• Hum and noise: Better than 40 dB below rated output.
• Harmonic Output Suppression: Better than
70dB below rated output.
• Input and Output
Impedances:
- nominal value: 50 Ohm unbalanced, Spinner (7/8"and
"N")type connectors;
- input circuit:
tuned,
VSWR <1.5:1
- Bypass path VSWR < 1:1,1, 50-52MHz continuously, 100 W maximum;
- Output (antenna)
impedance matching capability: VSWR up to 2:1
• Protection
circuits:Ia>2000mA,Ig1>25mA,Ig2>40mA,TMP>75C,SWR>2,
• RF Gain: 18dB typically, frequency response
< 1dB (40W drive power for
rated output).
• Tube: Single
GU84B with
forced air cooling(200m3/h)
•
Primary Power: 220-240 V AC, 50-60 Hz, single phase, 150VA.
• Secondary HV
Power Supply: 220-240V or 400v AC, 50-60 Hz, btn 2 phase,
3600VA. (ME3000-S,
option)
•
Complies with CE safety and
electromagnetic compatibility requirements.
• FAN :built in
230V/80W AC fan PAPST 200m3/h
•
Size &
Weight : WxDxH: 19"x14"x7" ~24kg w/h HV supply.
• Operating environments:
- temperature range: 0...+50 degs.Celsius;
- humidity: up to 95% @ +35 degs.Celsius.
- height: up to 3000m above sea level without output
deterioration |
