Frequency
Coverage: 50-52MHz and 70-72MHz
amateur bands,switchable.
- Power
Output: 700W PEP or 500 W continuous carrier.
-
Intermodulation Distortion: Better than 35 dB below rated output.
- Hum and
noise: Better than 40 dB below rated output.
- Harmonic
Output Suppression: Better than 70 dB below rated output.
- Input and
Output Impedances:
- nominal value: 50 Ohm unbalanced, UHF ( 2x
"N") type connectors;
- input circuit: tuned, VSWR <1.3:1
- Bypass path VSWR < 1.1:1, 4/6m continuously, 100
W maximum;
- Output (common ant out) impedance matching
capability: VSWR up to 3:1
- Protection
circuits:Ia>550mA,Ig1>250mA,TMP>75C,SWR>2,RFinp
- RF Gain: 12-13dB
typically, frequency response < 1dB (30W drive power for
rated output).Tube GI46B.
- Built in
3-way PIC controlled sequencer.
- Primary
Power: 220-240 V AC, 50-60 Hz, single phase, 1300 VA.
- Complies with CE
safety and electromagnetic compatibility requirements.
- FAN :built
in 230V/15W AC fan PAPST type 4605,12V/0.12A DC fan.
- Size & Weight :
WxDxH: 410x340x185mm, ~25kg
Operating
environments:
- temperature range: 0...+50 degs.Celsius;
- humidity: up to 95% @ +35 degs.Celsius.
- height: up to 3000m above sea level without output
deterioration
|
